UO-D 3000 BW/FU
Item No. AX03:
5110060040
Item No. D365:
18231000098
Description
Brackish water reverse osmosis units for desalination of water with a salinity of up to 5,000 mg/l. Operation with recovery of 50 – 75 % depending on salt content in the feed water and target desalination rate. Each unit is equipped with a high-quality centrifugal pump, energy savings of 30 – 50 % due to design with variable-speed drive (VSD = FU).
The RO digital control system enables fully automatic operation with logging of all relevant operating data. The unit can be connected to the central control system via optional interfaces.
Features
- Complete unit skid mounted
- RO digital controller
- Permeate recovery 50-75%, depends on feed water salinity & desired desalination rate
- Adapted materials for resistance to high salt content in the concentrate
- Space-saving design due to vertical pressure pipes (up to 1000l/h)
- Possibility to control & connect two dosing stations
- Incl. connection kit for MRA manual cleaning unit (ARA)
- Incl. concentrate flushing device (KSE)
- Optional: Profinet, Profibus, Modbus RTU/TCP and BACnet interfaces
- Optional: SPS (PLC Siemens S7-1200) instead of RO digital
- Optional: PP version instead of PVC
| Permeate Flow | 3000 l/h |
| Membranes | 4040 x 12 |
| Controller | RO digital |
| Advantages | Advantages of RO units with VSD (FU)
|
No exploded view available
| Image | Reference | Product | Type |
|---|---|---|---|
|
5213000354 | Permeate Flushing Unit KVP 200 BW | Option |
|
|
5213000054 | PROFINET-Interface | Option |
|
|
5213000280 | PLC Siemens S7-1200 for UO-D FU, UO-D AS/FU & UO-D BW/FU | Option |
No related items available
No documentation available
